SGR™-AV FLAT-headed Coating Dowel?noresize

1 /

Product Description

 close-icon minus-icon

Supply and installation of 8 mm screwable anchor hole with 60 mm flat head for flush or concealed use, with double-thread screw pre-mounted in the anchor shaft. The Dowel can be automatically inserted during fixing and then covered with the appropriate EPS, EPS Graphite or Mineral Wool Plugs. Anchorage depth > 25 mm or inserted flush and then covered with the special polymer plug supplied with the Dowel.

The main new features of this new Line are:

  • Dowel with pre-mounted screw with significant reduction in installation time

  • 60 mm flat-head anchor for concealed or flush fixing

  • Dowel with simultaneous insertion and fixing with considerable reduction in laying time

  • Dowel with installation without milling dust release

  • Dowel with secure fastening and anchoring on all the most commonly used substrates

Materials used

 close-icon minus-icon

Stem and ferrule made of PP (polypropylene), steel screw.

Use

 close-icon minus-icon

Used for mechanical anchorage of insulation panels on all major types of masonry, supporting their load and tensile "pull" stress. Promoted screw greatly facilitates and speeds up the installation of anchors with obvious savings in installation time. The flat head allows concealed or flush fastening, reducing the consumption of the finish and ensuring better aesthetic performance

Articles

minus-icon
Product Code/Name Download Dimension Article Info
SGR™-AV FLAT plug hole Ø 8 - 115 mm Enlarge search-icon
TER11-3115AVF

SGR™-AV FLAT plug hole Ø 8 - 115 mm

close-icon
TD 		115 x ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 115 mm Enlarge search-icon
TER11-3135AVF

SGR™-AV FLAT plug hole Ø 8 - 115 mm

close-icon
TD 		135 x ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 155 mm Enlarge search-icon
TER11-3155AVF

SGR™-AV FLAT plug hole Ø 8 - 155 mm

close-icon
TD 		155 x Ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 175 mm Enlarge search-icon
TER11-3175AVF

SGR™-AV FLAT plug hole Ø 8 - 175 mm

close-icon
TD 		175 x Ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 195 mm Enlarge search-icon
TER11-3195AVF

SGR™-AV FLAT plug hole Ø 8 - 195 mm

close-icon
TD 		195 x Ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 215 mm Enlarge search-icon
TER11-3215AVF

SGR™-AV FLAT plug hole Ø 8 - 215 mm

close-icon
TD 		215 x Ø 8 mm
SGR™-AV FLAT plug hole Ø 8 - 235 mm Enlarge search-icon
TER11-3235AVF

SGR™-AV FLAT plug hole Ø 8 - 235 mm

close-icon
TD 		235 x Ø 8 mm

Download Legends

TD

TD

Technical Datasheet
