Fire Rated Access Panel

1 /

Product Description

 close-icon minus-icon

90 minute fire resistant inspection hatch (EI90) with built-in (Patented) fire protection and key lock.
2 x 25 mm flame retardant plasterboard and intumescent protection.
Individually Packaged in boxes.

Materials used

 close-icon minus-icon

Aluminum frame with intumescent coating and fire resistant plasterboard panel.

Use

 close-icon minus-icon

Used in self-contained dropped ceilings with fire protection EI90 (E = aptitude to block or produce flames, vapors or hot gases on the unexposed side; I = aptitude to reduce heat transmission.)

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Secutecna EI90 with key lock Enlarge search-icon
GAN01-6441

Secutecna EI90 with key lock

50 mm 300 x 300 mm
Secutecna EI90 with key lock Enlarge search-icon
GAN01-6443

Secutecna EI90 with key lock

50 mm 400 x 400 mm
Secutecna EI90 with key lock Enlarge search-icon
GAN01-6445

Secutecna EI90 with key lock

50 mm 500 x 500 mm
Securtecna EI90 with key lock Enlarge search-icon
GAN01-6446

Securtecna EI90 with key lock

50 mm 600 x 600 mm
Securtecna EI90 with key lock Enlarge search-icon
GAN01-6448

Securtecna EI90 with key lock

50 mm 800 x 800 mm
