Product Description

 close-icon minus-icon

CRM reinforced plaster is an intervention technique that is similar to the traditional one from an application point of view but takes advantage of the benefits of using innovative materials for nets, angles and connectors. These are in fact made of GFRP (Glass Fiber Reinforced Polymer), a composite material characterized by high tensile strength and that does not oxidize. The application with lime-based mortars makes the reinforcement system optimal for masonry buildings, even constrained ones. The system can be applied for the reinforcement of press-flexion and shear masonry males, the reinforcement of arches, vaults and domes, and the confinement of columns.

Materials used

 close-icon minus-icon

Prometheus™ DT consists of GFRP Dragonet structural meshes,

GFRP Draconnect L-connectors and GFRP 66/66 angle.

The intervention is then completed by M15 lime-based mortar, CE marked according to UNI EN 998:1 and 998:2, Bio Force One™, an element for localized stress distribution in the vicinity of the Circlenet™ connector, and VINYL MAGNEKON two-component chemical anchor in cartridge.

Use

 close-icon minus-icon

Reinforced plaster is a widely used technique for the consolidation and reinforcement of existing buildings. The plaster increases the compressive strength of the masonry, and the mesh brings improved tensile strength. The connectors, in addition to ensuring the transfer of strengths to the substrate, if through, ensure the connection of the masonry faces. Some examples of use of the Prometheus™ DT system are: reinforcement of masonry males in press-flexion and shear, reinforcement of arches, vaults and domes, and confinement of columns.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Dragonet - Structural Network 33 Enlarge search-icon
RET03-40330S

Dragonet - Structural Network 33

830 g/m2
Dragonet - Structural Network 66 Enlarge search-icon
RET03-40660S

Dragonet - Structural Network 66

450 g/m2
Dragonet - Structural Network 99 Enlarge search-icon
RET03-40990S

Dragonet - Structural Network 99

310 g/m2
