Product Description

 close-icon minus-icon

The DAKUA+ Base Square linear shower drain range guarantees high functionality combined with a modern aesthetic. This model can be placed as desired. The block body shower channel drain is made of AISI 304 stainless steel that, thanks to the absence of bends, welds and screws, ensures an easy cleaning for high hygiene standards.

The flow rate (44 litres/min) is high, even with lowered heights. All gratings are interchangeable and available in polished, brushed steel or glass. The kit is composed of:

- A preassembled grating, ready for installation.

- A waterproof polyester sheet , shaped on the edge of the channel.

- A shower channel body and a stainless steel grating with glass coating.

- ABS siphoned cup with joint and gasket

This shower channel is suitable for flat flooring and open showers, improves the aesthetics of the bathroom's floor surface whilst effectively collecting used shower waters.

Materials used

 close-icon minus-icon

Stainless steel (channel and grating) - ABS (siphon and outlet body) - Waterproof polyester fabric (waterproofing sheet)

Use

 close-icon minus-icon

This channel is used for the collection of the shower water. It fits perfectly with the floor embellishing the surface aesthetics.

Articles

minus-icon
Product Code/Name Download Dimension Article Info
Dakua+ Base with Stainless Steel Grating Square Kit - 600 Enlarge search-icon
POZ93-12600/Q

Dakua+ Base with Stainless Steel Grating Square Kit - 600

78 x 600 mm
Dakua+ Base with Stainless Steel Grating Square Kit - 700 Enlarge search-icon
POZ93-12700/Q

Dakua+ Base with Stainless Steel Grating Square Kit - 700

78 x 700 mm
Dakua+ Base with Stainless Steel Grating Square Kit - 800 Enlarge search-icon
POZ93-12800/Q

Dakua+ Base with Stainless Steel Grating Square Kit - 800

78 x 800 mm
Dakua+ Base with Stainless Steel Grating Square Kit - 900 Enlarge search-icon
POZ93-12900/Q

Dakua+ Base with Stainless Steel Grating Square Kit - 900

78 x 900 mm

Do you need product support?

Request a sample or contact us for any need.
